The HD3SS214 is a high-speed passive switch capable of switching from one of two sources to one destination in two complete DisplayPort 4-lane port applications. It also switches a source to one of two sinks. For DisplayPort applications, the HD3SS214 supports switching Auxiliary (AUX), Display Data Channel (DDC) and Hot Plug Detect (HPD) signals in the nFBGA ZXH package.

Specification

Application Simulation

Multiplexer/Demultiplexer circuit 2:1

switch circuit -

Number of channels 2

On-resistance (max) 12 ohms

Voltage - Power, Single (V+) 3V ~ 3.6V

Voltage - Supply, Dual (V±) -

-3db bandwidth 500MHz

Features Differential Compatibility

Operating temperature 0°C ~ 70°C (TA)

Mounting Type Surface Mount

Package/Case 50-VFBGA

Vendor Device Package 50-BGA MicroStar Junior (5x5)

Application

• PCs and laptops

• tablet

• Connected peripherals and printers
