The AD8065ARTZ is a high-performance voltage-feedback FET input operational amplifier from ADI, part of the FastFET™ series, manufactured using XFCB process ‌. This amplifier is mainly applied in fields such as medical instruments, communication systems, automotive electronics and industrial control, featuring outstanding performance and wide applicability.

The AD8065ARTZ amplifier features a wide supply voltage range of 5 V to 24 V, can be powered by a single supply, and has a bandwidth of 145 MHz, making it suitable for a wide range of applications. In addition, this amplifier also features rail-to-rail output, making its functions more diverse.

Technical parameters

Amplifier type: Voltage feedback

Number of circuits: 1

Output type: Full swing

Pressure swing rate: 180V/µs

-3db bandwidth: 145 MHz

Current - Input bias: 3 pA

Voltage - Input compensation: 400 µV

Current - Power supply: 6.6mA

Current - Output/Channel: 30 mA

Voltage - Span (minimum value) : 5 V

Voltage - Span (maximum value) : 24 V

Operating temperature: -40°C to 85°C

Installation type: Surface mount type

Packaging/Shell: SOT-23-5

In addition, the AD8065ARTZ performs outstandingly in the following scenarios:

Automobile driver assistance system

Photodiode preamplifier

Filter

ADC driver

Level conversion

Buffer
