R7F701412EABG is a 32-bit automotive-grade microcontroller belonging to the RH850/D1M2H series, specifically designed for applications such as in-vehicle instrument clusters, HUD (head-up displays), and advanced graphical HMI (human-machine interfaces). The chip is manufactured using a 40nm process, complies with the ISO 26262 ASIL-B to ASIL-D functional safety standards, and integrates a high-performance graphics engine and large-capacity storage, making it suitable for high-resolution display systems and complex data processing requirements.

R7F701412EABG Product Specifications

Series: RH850/D1M

Core Processor: RH850G3M

Core Specifications: 32-bit single-core

Speed: 240MHz

Connectivity: CANbus, EBI/EMI, Ethernet, I2C, LINbus, SCI, SPI, SSI, UART/USART, USB

Peripherals: DMA, I2S, LCD, LVD, POR, PWM, WDT

I/O Count: 199

Program Memory Capacity: 3.75MB (3.75M x 8)

Program Memory Type: Flash

EEPROM capacity: 64K x 8

RAM size: 512K x 8

Voltage - Power supply (Vcc/Vdd): 2.7V to 5.5V

Data converter: A/D 20x12b

Oscillator type: Internal

Operating temperature: -40°C to 150°C (TJ)

Mounting type: Surface mount

Supplier device package: 484-BGA (27x27)

Typical Applications

Digital instrument clusters (TFT/LCD display drivers)

HUD (Head-Up Display) (supports dynamic image correction)

In-vehicle infotainment systems (IVI) (multi-screen interaction)

ADAS (Advanced Driver Assistance Systems) (data processing and display)
