EFM32TG210F32-D-QFN32R is 32-Bit Single-Core ARM Cortex-M3 32MHz Tiny Gecko Microcontroller.

EFM32TG210F32-D-QFN32R offers unmatched performance and ultra low power consumption in both active and sleep modes. EFM32TG devices consume as little as 0.6 μA in Stop mode and 150 μA/MHz in Run mode. It also features autonomous peripherals, high overall chip and analog integration, and the performance of the industry standard 32-bit ARM CortexM3 processor, making it perfect for battery-powered systems and systems with high-performance, low-energy requirements.

Specification Of EFM32TG210F32-D-QFN32R

Core: ARM Cortex M3

Program Memory Size: 32 kB

Data Bus Width: 32 bit

ADC Resolution: 12 bit

Maximum Clock Frequency: 32 MHz

Number of I/Os: 24 I/O

Data RAM Size: 4 kB

Supply Voltage - Min: 1.98 V

Supply Voltage - Max: 3.8 V

Minimum Operating Temperature: - 40 ℃

Maximum Operating Temperature: + 85 ℃

DAC Resolution: 12 bit

Data RAM Type: RAM

I/O Voltage: 3.83 V

Interface Type: I2C, SPI, UART, USART

Number of ADC Channels: 4 Channel

Number of Timers/Counters: 2 x 16 bit

Processor Series: Tiny Gecko

Features Of EFM32TG210F32-D-QFN32R

ARM Cortex-M3 at 32 MHz

Ultra low power operation

0.6 μA current in Stop (EM3), with brown-out detection and RAM retention

51 μA/MHz in EM1

150 μA/MHz in Run mode (EM0)

Fast wake-up time of 2 µs

Hardware cryptography (AES)

Up to 32 kB of Flash and 4 kB of RAM

Applications Of EFM32TG210F32-D-QFN32R

Smart metering

Water metering

Gas metering

Industrial and home automation

Alarm and security systems

Health and fitness applications
