Commodity Model:STB120NF10T4

Trade Name:N-Channel Power MOSFET

Brand:ST

Particular Year:18+

Package:TO-263

Delivery Date:New and Original

Stock: 32000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ST
Model
STB120NF10T4
Package
TO-263
Describe
N-channel 100 V, 9 mOhm typical, 110 A STripFET II power MOSFET, D2PAK package

Product Description

STB120NF10T4 is an N-channel enhancement-mode power MOSFET launched by STMicroelectronics, belonging to the STripFET™ II series, using TO-263-3 (D2PAK) packaging, suitable for high-current, high-voltage applications. This device features low on-resistance and high switching speed, and is widely used in power management, motor drive, industrial control and other fields.


STB120NF10T4 Product Attributes

Product Type: MOSFET

Technology: Si

Mounting Style: SMD/SMT

Package/Case: D2PAK-3 (TO-263-3)

Transistor Polarity: N-Channel

Number of Channels: 1 Channel

Vds - Drain-Source Breakdown Voltage: 100 V

Id - Continuous Drain Current: 110 A

Rds On - Drain-Source On-Resistance: 10.5 mOhms

Vgs - Gate-Source Voltage: -20 V, +20 V

Vgs th - Gate-Source Threshold Voltage: 2 V

Qg - Gate Charge: 172 nC

Minimum operating temperature: -55°C

Maximum operating temperature: +175°C

Power dissipation (Pd): 312 W

Channel mode: Enhancement


STB120NF10T4 Key Features

Low on-resistance: 10.5 mΩ @ 60 A, 10 V, reducing conduction losses and improving efficiency.

High current carrying capacity: 110 A continuous current, suitable for high-power switching applications.

Fast switching performance: Rise time 90 ns, fall time 68 ns, optimising PWM control efficiency.

Industrial-grade reliability: 100% avalanche testing ensures device stability under high-voltage transients.

Compliant with RoHS standards, lead-free packaging, suitable for environmentally stringent applications.
