STM8L152R8T6 is an ultra-low-power 8-bit microcontroller (MCU) from STMicroelectronics, belonging to the STM8L EnergyLite family, available in a 64-LQFP package (10×10mm) for battery-powered devices, industrial control, smart home and medical electronics.

STM8L152R8T6 Core Features

Ultra-low power design

Multiple low-power modes: standby mode (0.4μA), shutdown mode (400nA)

Dynamic operation power consumption: 192μA/MHz to optimise battery life

High performance 8-bit STM8 core

16MHz main frequency, supports 16 CISC MIPS peak performance

Harvard architecture + 3-stage pipeline to improve instruction execution efficiency

Large storage capacity

64KB Flash (supports self-programming)

4KB RAM + 2KB EEPROM (data storage)

Rich Peripheral Interface

12-bit ADC (28 channels, 1Msps)

2×12-bit DAC, 5 timers (1×8-bit + 4×16-bit)

Communication interface: I²C×1, SPI×2, USART×3

Industrial Grade Reliability

Operating temperature: -40°C ~ +85°C

Wide voltage supply: 1.8V ~ 3.6V (with BOR reset protection)

STM8L152R8T6 Product Attributes

Product Category: 8-bit Microcontrollers -MCUs

Core: STM8

Programme memory size: 64 kB

Data RAM size: 4 kB

Package / Case: LQFP-64

Maximum clock frequency: 16 MHz

ADC resolution: 12 bit

Number of inputs/outputs: 54 I/Os

Supply voltage - min: 1.8 V

Supply voltage - max: 3.6 V

Mounting style: SMD/SMT

Data bus width: 8 bit

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

STM8L152R8T6 Typical Applications

Smart home: smart lighting, temperature control systems

Industrial automation: PLC, sensor nodes

Medical devices: portable monitors, blood glucose meters

Consumer electronics: smart watches, wireless sensors
