For picture reference, please see the specifications
< >

Commodity Model:PIC18F66K80-I/PT

Trade Name:8-bit Microcontroller - MCU

Brand:Microchip

Particular Year:22+

Package:TQFP64

Delivery Date:New and Original

Stock: 2880pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Microchip
Model
PIC18F66K80-I/PT
Package
TQFP64
Describe
8-bit microcontroller - MCU 64KB FL 4KBRM 16MIPS 12-bit ADC CTMU

Product Description

PIC18F66K80-I/PT is a high-performance 8-bit microcontroller belonging to the PIC18 series. It employs an enhanced Harvard architecture, featuring low power consumption, high performance, and rich peripheral integration, making it suitable for a wide range of embedded applications.


PIC18F66K80-I/PT Specifications

Core Processor: PIC18

Core Specification: 8-bit

Maximum Clock Frequency: 64 MHz

Program Memory Capacity: 64KB (32K x 16) Flash

EEPROM Capacity: 1K x 8

RAM Size: 3.6K x 8

Number of Input/Output Pins: 54 I/O

Data Converter: A/D 11x12b

Oscillator Type: Internal

Operating Voltage Range: 1.8V to 5.5V

Operating Temperature Range: -40°C to +85°C (TA)

Package Type: TQFP-64 (10x10)

Mounting Type: Surface Mount

Interface Capabilities: ECANbus, I2C, LINbus, SPI, UART/USART

Peripherals: Undervoltage Detection/Reset, LVD, POR, PWM, WDT


PIC18F66K80-I/PT Features

Low-Power Design: Utilises nanoWatt XLP technology, highly suitable for battery-powered applications.

Low Sleep Current: 20 nA in sleep mode, 300 nA during watchdog timer operation.

Integrated ECAN: Compliant with current CAN 2.0B specification.

Wide Operating Voltage Range: 1.8V to 5.5V, suitable for diverse application scenarios.

High-Precision Analogue Interface: 11-channel 12-bit ADC.

Charge Time Measurement Unit: CTMU supports touch sensing and advanced sensing applications.

Multiple Communication Interfaces: Supports SPI, I²C, UART/USART, and ECAN bus.

Self-Programming Flash Memory: Supports 10k erase/write cycles and 20-year data retention.


PIC18F66K80-I/PT Applications

Industrial automation control: Suitable for PLC controllers, sensor acquisition modules, motor control, etc.

Smart metering and data acquisition: Suitable for temperature/humidity sensors, pressure transmitters, power monitoring modules, etc.

Vehicle electronics: Commonly used in OBD interface devices, lighting control, on-board diagnostic systems, etc.

Home Appliance Control Boards: Suitable as the main control chip for appliances such as air conditioners, washing machines, and smart rice cookers.

Building Control and Lift Control: Suitable for various building automation and lift control systems.
