For picture reference, please see the specifications
< >

Commodity Model:PAFSC5G35E37R9

Trade Name:Power Amplifier Module

Brand:NXP

Particular Year:19+

Package:HLQFN-26

Delivery Date:New and Original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
NXP
Model
PAFSC5G35E37R9
Package
HLQFN-26
Describe
5G/LTE Power Amplifier Module Designed for 5G and LTE Communication Devices

Product Description

PAFSC5G35E37R9 is a 5G/LTE power amplifier module designed for 5G and LTE communication equipment, suitable for base stations, small base stations, CPE (Customer Premises Equipment) and other application scenarios.


PAFSC5G35E37R9 Core Features

High frequency band support:

Operating frequency range: 3400MHz ~ 3600MHz (3.5GHz 5G band).

Suitable for 5G NR (New Air Port) and LTE Advanced Pro networks.

High output power:

P3dB Output Power: 36.3W (typical), 45.6dBm (typical).

Ideal for high-power wireless communications equipment such as 5G base station RF front ends.

High efficiency design:

Typical efficiency: 39.2%2, optimising power performance and reducing system heat.

Integrated matching network:

Optimised input/output impedance matching reduces the need for external components and simplifies PCB design.

Packaging and Dimensions:

HLQFN-26 package (10mm × 6mm), compact design for high-density RF front-end integration.


PAFSC5G35E37R9 Typical Applications

5G base stations (AAU/RRU)

LTE/5G Small Cell Base Station (Small Cell)

Fixed Wireless Access (FWA) devices

Industrial Internet of Things (IIoT) communication terminals

Associated Products

Model

Brand

Package

Quantity

Describe

A5M37SG239T2

NXP

QFN-34

2000

3450-3980 MHZ, 35dB, average 8W Airfast® power amplifier module

QPM1017

Qorvo

SMD

2000

5.7 – 7 GHz 100 W GaN Power Amplifier Module

A3M34TL139T2

NXP

HLQFN26

2000

3300-3580 MHz, 28 dB, 7 W average Airfast® Power Amplifier Module

A3M36SL037IAAT2

NXP

Module

2000

3400-3800MHz, 29dB, 5W Average Airfast® Power Amplifier Module (with Auto Bias Control)

A3M39SL039IAAT2

NXP

Module

2000

3700-3980 MHz, 28 dB, Average 8 W Airfast® Power Amplifier Module (with Auto Bias Control)

AFSC5G35D35T2

NXP

26-LQFN

3000

Power Amplifier Module for LTE and 5G
