HDC2010YPAR is an integrated humidity and temperature sensor that uses ultra compact WLCSP (wafer level chip level package) to provide high-precision measurements with ultra-low power consumption. The sensing element of HDC2010YPAR is located at the bottom of the device, which helps HDC2010 resist the influence of dust, dirt, and other environmental pollutants, making it more stable and reliable. This capacitive sensor includes new integrated digital features and heating elements for dissipating condensation and moisture. The HDC2010YPAR digital features include programmable interrupt thresholds, allowing for alarm/system wake-up without the need for a microcontroller to continuously monitor the system. Meanwhile, HDC2010YPAR features programmable sampling intervals, low inherent power consumption, and supports a 1.8V power supply voltage, making it highly suitable for battery powered systems.

HDC2010YPAR provides high-precision measurement capabilities for various environmental monitoring applications and the Internet of Things (IoT), such as smart thermostats, smart home assistants, and wearable devices. HDC2010YPAR can also be used to provide critical temperature and humidity data for cold chain transportation and storage of perishable goods, to help ensure fresh delivery of products such as food and medicine.

HDC2010YPAR has been factory calibrated with a temperature accuracy of 0.2 ° C and a relative humidity accuracy of 2%. It is equipped with heating elements that can eliminate condensation and moisture, thereby increasing reliability. The HDC2010YPAR supports a working temperature range of -40 ° C to 125 ° C and a relative humidity range of 0% to 100%.

Parameters Of HDC2010YPAR:

Product type: Onboard humidity sensor

RH range: 0% to 100%

RH accuracy:+/-2%

Installation style: SMD/SMT

Output type: Digital

Interface type: I2C

Resolution: 14 bits

Full temperature accuracy:+/-0.2 ° C

Working power supply current: 550 nA

Power Supply Voltage - Minimum: 1.62 V

Power Supply Voltage - Maximum: 3.6 V

Minimum operating temperature: -40 ° C

Maximum operating temperature:+85 ° C

Package/Box: DSBGA-6

Features Of HDC2010YPAR

• Relative humidity range: 0% to 100%

•Humidity accuracy: ± 2%

• Sleep current: 50nA

• Average power supply current (measured once per second)

- RH only (11th position): 300nA

- RH (11 digits)+temperature (11 digits): 550nA

• Temperature range:

- Work: -40 ° C to 85 ° C

- Can be used: -40 ° C to 125 ° C

• Temperature accuracy: Typical value ± 0.2 ° C

• Power supply voltage: 1.62V to 3.6V

• Programmable sampling rates (5Hz, 2Hz, 1Hz, 0.2Hz, 0.1Hz, 1/60Hz, 1/120Hz) or trigger as needed

• I2C interface

Application Of HDC2010YPAR

•Smart thermostat

•Smart Home Assistant

• Refrigerator

• Refrigerated transportation

• Washing machine/dryer

•HVAC system

• Gas detection

• Communication equipment

• Environmental labels

• Smoke and heat detectors

• Inkjet printer

• Surveillance cameras

•CPAP ventilator

• Wearable devices
