The MC9S12XD series introduces the performance enhancing XGATE module. Using enhanced DMA functionality, this parallel processing module eases the burden on the CPU by providing high-speed data processing and transfers between peripheral modules, RAM, Flash EEPROM and I/O ports. XGATE provides the CPU with up to 80 MIPS of additional performance with access to all peripherals, Flash EEPROM and RAM blocks.

Product Properties

Product Category: 16-bit Microcontrollers - MCU

Series: S12XD

Mounting Style: SMD/SMT

Package / Case: LQFP-112

Core: HCS12X

Program memory size: 256 kB

Data bus width: 16 bit

ADC resolution: 10 bit

Max. clock frequency: 40 MHz

Number of inputs/outputs: 91 I/O

Data RAM size: 16 kB

Supply voltage - min: 2.5 V

Supply voltage - max: 2.5 V

Min. operating temperature: - 40 C

Max. operating temperature: + 125 C

Qualification: AEC-Q100

Height: 1.4 mm

Interface type: CAN, I2C, SCI, SPI

Length: 20 mm

Humidity sensitivity: Yes

Number of ADC channels: 16 Channel

Number of timers/counters: 12 Timer

Product type: 16-bit Microcontrollers - MCU

Program memory type: Flash

Number of Factory Packages: 300

Sub Category: Microcontrollers - MCU

Width: 20 mm

Unit weight: 1.278 g
