ISL99227HRZ have integrated high accuracy current and temperature monitors that can be fed back to the controller and doubler to complete a multiphase DC/DC system. They simplify design and increase performance by eliminating the DCR sensing network and associated thermal compensation. Light-load efficiency is supported via a dedicated LFET control pin. An industry leading thermally enhanced 5x5 PQFN package allows minimal overall PCB real estate. The ISL99227HRZ feature a 3.3V compatible, 5.0V compatible tri-state PWM input that, working together with multiphase PWM controllers, provide a robust solution in the event of abnormal operating conditions. The ISL99227HRZ also improve system performance and reliability with integrated fault protection of UVLO, over-temperature, and overcurrent. An open-drain fault reporting pin simplifies the handshake between SPS and controllers and can be used to disable the controller during start-up and fault conditions.

Features Of ISL99227HRZ

Input range: +4.5V to +18V

Supports 60A DC current

ISL99227 with 3.3V compatible tri-state PWM input

ISL99227B with 5.0V compatible tri-state PWM input

Downslope current sensing

±3% accuracy current monitor (IMON) with REFIN input

8mV/°C temperature monitor with OT flag

Dedicated low-side FET control input

Comprehensive fault protection for high system reliability

High-side FET short and overcurrent protection

Over-temperature protection

VCC and VIN Undervoltage Lockout (UVLO)

Open-drain fault reporting output

Up to 2MHz switching frequency

RoHS compliant with Exemption 7a, 32 Ld 5x5 PQFN

Applications Of ISL99227HRZ

High frequency and high efficiency VRM and VRD

Core, graphic, and memory regulators for microprocessors

High density VR for server, networking, and cloud computing

POL DC/DC converters and video gaming consoles
