RAA279971D3HNP: Video Encoder - Automotive HD Link Encoder, SQFN-32

Model: RAA279971D3HNP

Package: SQFN-32

Type: HD Video Encoder

The RAA279971D3HNP is an analogue HD video encoder designed for automotive applications. It accepts digital video inputs using a dual-channel MIPI-CSI2 or DVP/pseudo BT.656 parallel interface and supports a wide range of HD resolutions up to 720p/60 or 1080p/30. The RAA279971D3HNP uses a built-in 10-bit video DAC to encode the incoming video stream into a combined analogue format, which is transmitted as a single-ended or differential signal to the RAA279972 decoder over up to 30 metres of coaxial or STP cable.

RAA279971D3HNP - Product Features:

Analogue Video Encoder

- Software-selectable controls allow single-ended, differential and pseudo-differential CVBS.

- 10-bit DAC

- Integrated PLL

- Internal test pattern generator

- Independent amplitude adjustment for brightness and chrominance

MIPI Inputs

- MIPI CSI2 1.1 compliant unidirectional output format

- YUV 422 input format, dual channel

- Shared minimum number of DVP/MIPI pins

- Supports 720p 30fps, 720p 60fps, 1080p 30fps and wide resolution for electronic mirror applications

Digital Inputs

- 10/8-bit digital video port parallel interface

- 10/8-bit pseudo BT.656 parallel interface

- Supports 720p 30fps, 720p 60fps, 1080p 30fps and wide resolution for electronic rear-view mirror applications

Other

- Low power consumption

- Power save and power down modes

- Bi-directional two-wire digital control channel

- Dual in-line control interface

- 27MHz single crystal operation

- 3.3V or 1.8V selectable I/O

- 32 Ld SQFN (5mm x 5mm QFN with step cut pins)
