Service Telephone:86-755-83294757
Trade Name:Embedded - Microcontrollers
Data Manual:LPC1788FET208.pdf
Brand:NXP
Particular Year:23+
Package:TFBGA-208
Delivery Date:New and Original
Stock: 2000pcs
The LPC1788FET208 is an ARM Cortex-M3 based microcontroller for embedded applications requiring high integration and low power consumption.The LPC1788FET208 is a next-generation core that delivers higher performance than the ARM7 at the same clock frequency and features other system enhancements such as modern debugging capabilities and a higher level of support block integration. The LPC1788FET208 integrates a 3-stage pipeline with a Harvard architecture with separate local instruction and data buses, as well as a slightly lower performance third bus for peripherals, and peripherals.
The LPC1788FET208 adds a dedicated Flash accelerator for optimal performance when executing code from Flash memory, and operates at CPU frequencies up to 20MHz.
Product Attributes
Core Processor: ARM® Cortex®-M3
Core specification: 32-bit single core
Speed: 120MHz
Connectivity: CANbus, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SP, ART/USART, USB OTG
Peripherals: Undervoltage Detect/Reset, DMA, I²S, Motor Control PWM, POR, PWM, WDT
Number of I/O: 165
Program memory capacity: 512KB (512K x 8)
Program memory type: Flash
EEPROM Size: 4K x 8
RAM Size: 96K x 8
Voltage - Supply (Vcc/Vdd): 2.4V ~ 3.6V
Data Converter: A/D 8x12b; D/A 1x10b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package/Housing: 208-TFBGA
Supplier Device Package: 208-TFBGA (15x15)
Applications
• Communications
• Industrial/Medical
• Consumer Goods/Electrical Appliances
• Automotive
