The ADUC7023BCBZ62I is a high-performance embedded microcontroller belonging to the ADuC7023 family. ‌ADUC7023BCBZ62I integrates a 1 MSPS, 12-bit data acquisition system with a high-performance multi-channel ADC, a 16-bit / 32-bit MCU, and Flash/EE memory. The ADC has up to 12 single-ended input channels and another four channels can be multiplexed with four DAC output pins, supporting single-ended and differential input modes with input voltage ranges from 0 V to VREF. The ADC is also equipped with a low drift bandgap reference voltage source, a temperature sensor, and a voltage comparator ‌.

Application field

The ADUC7023BCBZ62I is suitable for a wide range of applications, including:

Optical fiber network

Industrial control and automation systems

Smart sensors, precision instruments

Base station system

ADUC7023BCBZ62I -- Technical specification

Core: ARM7TDMI

Program memory size: 62 kB

Data bus width: 32 bit/16 bit

ADC resolution: 12 bit

Max clock frequency: 41.78MHz

Number of inputs/outputs: 16 I/ OS

Data RAM size: 8 kB

Supply voltage: 2.7V to 3.6V

Operating temperature: -40 °C to + 125°C

Package/box: WLCSP-36

Analog supply voltage: 2.7V to 3.6V

DAC resolution: 12 bit

Data Ram type: SRAM

I/O voltage: 2.7V to 3.6V

Interface type: I2C, SPI

Number of ADC channels: 10 channels

Number of timers/counters: 2 Timer

Processor series: ADuC7023

Product: MCUs

Product type: ARM Microcontroller-MCU

Program memory type: Flash
