FT4232HL: USB Device IC - High Speed Quad USB UART IC, LQFP-64

Model: FT4232HL

Package: LQFP-64

Type: USB UART IC

FT4232HL is FTDI's 5th generation USB device IC. FT4232H is a USB2.0 High Speed (480 Megabits per second) to UART IC. It has the ability to be configured in a variety of industry standard serial port configurations.

The FT4232HL has four UARTs, two of which have the Multi-Protocol Synchronous Serial Engine (MPSSE) option, allowing the FT4232H to use two UART/Bit-Bang interfaces plus two Multi-Protocol Synchronous Serial Engines to emulate JTAG, SPI, I2C, Bit-Bang or other synchronous serial modes.

FT4232HL - Key Hardware Features:

Single chip USB to quad serial port with various configurations

Entire USB protocol handled by the chip, USB does not require specific firmware programming

USB 2.0 high speed transfer (480 megabits per second) and full speed (12 megabits per second) compatible

Independent baud rate generator

RS232/RS422/RS485 serial port transfers at data rates up to 12 megabaud

Highly integrated design includes +1.8V LDO regulator, integrated POR function and on-chip pulse doubling PLL (12MHz-480MHz)

Operational configuration modes and USB description strings configured via external EEPROM via USB interface

Configurable IO drive strength (4,8,12 or 16 mA) and slew rate

Supports bus-powered, self-powered and high-power bus-powered USB configurations

+1.8V (chip core) and +3.3V I/O interface (+5V withstand)

Extended industrial operating temperature range -40°C to 85°C

+ 3.3V single supply operating voltage range
