The STM32F103RCT6 performance line family integrates a high-performance Arm® Cortex®-M3 32-bit RISC core operating at 72 MHz with high-speed embedded memory (up to 512 KB for Flash and 64 KB for SRAM) and a large number of enhanced I/Os and peripherals connected to two APB buses. All devices offer three 12-bit ADCs, four general-purpose 16-bit timers and two PWM timers, as well as standard and advanced communication interfaces: up to two I2C, three SPI, two I2S, one SDIO, five USART, one USB and one CAN.

The STM32F103RCT6 high-density performance line family operates over the -40 to +105°C temperature range and is powered from a 2.0 to 3.6V supply. A comprehensive set of power-saving modes allows the design of low-power applications.

Product attributes

Product Type: ARM Microcontrollers - MCU

Family: STM32F103RC

Mounting Style: SMD/SMT

Package / Case: LQFP-64

Core: ARM Cortex M3

Program memory size: 256 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Max. clock frequency: 72 MHz

Number of inputs/outputs: 51 I/O

Data RAM size: 48 kB

Supply voltage - min: 2 V

Supply voltage - max: 3.6 V

Min. operating temperature: - 40 C

Max. operating temperature: + 85 C

Data Ram type: SRAM

Height: 1.4 mm

Interface type: CAN, I2C, SPI, USART, USB

Length: 10 mm

Humidity sensitivity: Yes

Number of ADC channels: 16 Channel

Number of timers/counters: 8 Timer

Processor family: ARM Cortex M

Program memory type: Flash

Number of Factory Packages: 960

Brand Name: STM32

Width: 10 mm

Unit weight: 342.700 mg
