NAFE13188B40BSK: High Speed AFE - Highly Configurable 8-Channel, ±25V General Purpose Input Analog Front End

Model: NAFE13188B40BSK

Package: HVQFN-64

Type: High Speed AFE - Analog Front End

Overview:

The NAFE13188B40BSK is a highly configurable, industrial-grade, multi-channel, general-purpose input analog front-end (AFE) that meets the requirements of high-precision measurements. The device integrates a low leakage high voltage (HV) fast multiplexer, low offset and low drift programmable gain amplifiers (PGAs) and buffers, a high data rate 24-bit Δ-∑ analog-to-digital converter (ADC), accurate voltage and current excitation sources, and a low drift voltage reference.

NAFE13188B40BSK - Key Features:

Built-in temperature sensor with ±3⁰C accuracy

Precision excitation voltage and current sources

Built-in oscillator accuracy of 0.2% at room temperature

Diagnostic system for fault detection and prediction

CRC error detection

10 GPIOs

32MHz SPI interface

Powerful 8kV HBM ESD and IEC61000-4-5 2kV surge protection

Power supply: ±7V to ±24V for high voltage, 3.3V for low voltage

Power consumption: 150mW for low-power version, 160mW for high-speed version

Operating temperature range TA: -40⁰C to +125⁰C

Package: 64-pin, 9mmx9mmx0.85mm HVQFN
