PSAS5-M213-0021TR: 68POS, SAS/PCIe 5.0 Connector, Storage Connector, Right Angle, Surface Mount

Model: PSAS5-M213-0021TR

Package: 68POS

Type: SAS/PCIe 5.0 (U.2 and U.3) Connector

Product Details: SAS PCIe, Storage Connector, 5.0, 68 Pin, Plug, Right Angle, Surface Mount

PSAS5-M213-0021TR - Product Attributes:

Connector Style: Plug

Connector Type: SAS/PCIe

Number of pins: 68

Mounting Type: Surface Mount, Right Angle

Termination: Solder

Features: Board Guide

Contact Finish: Gold Plated

Contact Finish Thickness: 30.0µin (0.76µm)

PSAS5-M213-0021TR (SAS/PCIe 5.0 Connector) Features:

Receptacle connector mates with unshielded dual port SFF8680 (SAS 3.0/SAS 4.0) connectors.

SAS/PCIe connector supports SFF8630, SFF8680 and SFF8432 interfaces

Backward compatible with 12Gb/s, 6Gb/s SAS, SATA and 3Gb/s SFF8482 connectors

Supports up to 6-port 32GT/s PCIe interfaces

Supports both SAS and SATA drives

Staggered contacts

Stamped fixing tabs act as connector retainers for robust PCB connections

Moulded guide posts provide angled access guidance to aid automatic alignment of mating components
