MSC130SM120JCU3 Full Silicon Carbide Power Module 1200V 173A N-Channel

Product Description

MSC130SM120JCU3 is Buck Chopper SiC MOSFET Power Module,1200 V, 173 A full Silicon Carbide power module.

Product Attributes

FET Type:N-Channel

Technology:SiCFET (Silicon Carbide)

Drain to Source Voltage (Vdss):1200 V

Current - Continuous Drain (Id) @ 25°C:173A (Tc)

Drive Voltage (Max Rds On, Min Rds On):20V

Rds On (Max) @ Id, Vgs:16mOhm @ 80A, 20V

Vgs(th) (Max) @ Id:2.8V @ 2mA

Gate Charge (Qg) (Max) @ Vgs:464 nC @ 20 V

Vgs (Max):+25V, -10V

Input Capacitance (Ciss) (Max) @ Vds:6040 pF @ 1000 V

Power Dissipation (Max):745W (Tc)

Operating Temperature:-55°C ~ 150°C (TJ)

Mounting Type:Chassis Mount
