PTX100RDQ56D13 - High-performance, High-power Multi-protocol NFC Forum Reader

PTX100RDQ56D13 - Product Description:

PTX100RDQ56D13 is a highly integrated NFC reader IC for contactless communication with increased key performance parameters such as output power (transmitter current up to 650mA) and RX sensitivity (-80dBc 1). While eliminating EMC filter and matching components, the PTX100R enables simple integration and compact design without the complexity associated with existing solutions (dual resonating circuits composed by EMC filter and antenna).

PTX100RDQ56D13 - Key Features:

High output power up to 2W @5.5V

Very high Receiver sensitivity (-80dBc)

DiRAC: Direct antenna connection for Tx and Rx

Sine Wave output Accurate Digital Wave Shaping

Removal of second resonating structure introduced by EMI

Xtal-less design using reference clock

PTX100RDQ56D13 - Block Diagram:
