Service Telephone:86-755-83294757
Trade Name:SN74HCS595PWR
Data Manual:SN74HCS595PWR.pdf
Brand:TI
Particular Year:21+
Package:TSSOP16
Delivery Date:New and Original
Stock: 1500pcs
The SN74HCS595 device contains an 8-bit, serialin, parallel-out shift register that feeds an 8-bit D-type storage register. All inputs include Schmitttrigger architecture, eliminating any erroneous data outputs due to slow-edged or noisy input signals. The storage register has parallel 3-state outputs. Separate clocks are provided for both the shift and storage register. The shift register has a direct overriding clear (SRCLR) input, serial (SER) input, and a serial output (QH') for cascading. When the output-enable (OE) input is high, the storage register outputs are in a high-impedance state. Internal register data and serial output (QH') are not impacted by the operation of the OE input.
Features
• Wide operating voltage range: 2 V to 6 V
• Schmitt-trigger inputs allow for slow or noisy input signals
• Low power consumption
– Typical ICC of 100 nA
– Typical input leakage current of ±100 nA
• ±7.8-mA output drive at 6 V
• Extended ambient temperature range: –40°C to +125°C, TA
Applications
• Output expansion
• LED matrix control
• 7-segment display control
• 8-bit data storage
