Commodity Model:ADRF5532BCPZN

Trade Name:RF Front End

Brand:ADI

Particular Year:24+

Package:LFCSP-24

Delivery Date:New and Original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
ADRF5532BCPZN
Package
LFCSP-24
Describe
2.3 GHz to 2.7 GHz, Receiver Front End

Product Description

ADRF5532BCPZN - 2.3 GHz to 2.7 GHz, Receiver Front End


Product Overviews

ADRF5532BCPZN is an integrated RF, front-end multichip module designed for time division duplex (TDD) applications. The device operates from 2.3 GHz to 2.7 GHz. The ADRF5532 is configured with a low-noise amplifier (LNA) and a high-power, silicon, single pole double throw (SPDT) switch. In the receive operation at 2.6 GHz, the LNA offers a low noise figure (NF) of 1.2 dB and a high gain of 35.5 dB with a third order input intercept point (IIP3) of −4 dBm.


Key Features

Integrated RF front end

LNA and high-power silicon SPDT switch

On-chip bias and matching

Single-supply operation

Gain: 35.5 dB typical at 2.6 GHz

Gain flatness: 0.2 dB at 25°C across 400 MHz bandwidth

Low noise figure: 1.2 dB typical at 2.6 GHz

Low insertion loss: 0.7 dB typical at 2.6 GHz

High-power handling at TCASE = 105°C

Full lifetime

LTE average power (8 dB PAR): 36.5 dBm

Single event (<10 sec operation)

LTE average power (8 dB PAR): 39 dBm

High Input IP3: −4 dBm

Low-supply current

Receive operation: 118 mA typical at 5 V

Transmit operation: 15 mA typical at 5 V

Positive logic control

5 mm × 3 mm, 24-lead LFCSP package

Pin compatible with the ADRF5534, 3.1 GHz to 4.2 GHz receiver front end


Applications

Wireless infrastructure

TDD massive multiple input and multiple output (MIMO) and active antenna systems

TDD-based communication systems


Associated Products

Model

Brand

Package

Quantity

Describe

AD8285WBCPZ

ADI

LFCSP-72

3000

Radar receiving path AFE: 4 channels, LNA/PGA/AAF, integrated ADC

SKY85767-11

Skyworks

QFN

20000

Highly integrated 5GHz RF front-end module (FEM)

QPF1003Q

Qorvo

QFN

2000

5 GHz C-V2X/DSRC/Wi-Fi Front End Module for Automotive

ADRF5539BCPZN

ADI

QFN

5000

High-performance RF receiver front-end chips

RF5426TR13

Qorvo

QFN

5000

RF Front-End ICs for High Performance RF Signal Processing

STA5635

ST

QFN-40

2000

RF Front End ADS INFOTAINMENT

QPF4509

Qorvo

QFN-16

3000

5 GHz Wi-Fi 7 High Power Front End Module

QPF4609

Qorvo

QFN-16

3000

6 GHz Wi-Fi 7 High Power Front End Module

QM42195SR

Qorvo

QFN

2000

High Performance RF FEM Module Designed for 802.11ax 2.4GHz WiFi Applications

ADL5961ACCZ

ADI

LGA-26

3000

9kHz to 26.5GHz, Integrated Vector Network Analyser (VNA) Front End, LGA-26
