The ACPL-K30T is specially designed to drive high-voltage MOSFETs. It consists of an AlGaAs infrared Light-Emitting Diode (LED) input stage optically coupled to an output detector circuit. The detector consists of a high-speed photovoltaic diode array and a turn-off circuit. The photovoltaic driver is turned on (contact closes) with a minimum input current of 5 mA through the input LED. The relay driver is turned off (contact opens) with an input voltage of 0.8 V or less.

ACPL-K30T is available in the stretched SO-8 package outline, designed to be compatible with standard surface mount processes.

R2Coupler isolation products provide reinforced insulation and reliability that delivers safe signal isolation critical in automotive and high-temperature industrial applications.

Features

• Qualified to AEC-Q100 Grade 1 Test Guidelines

• Automotive temperature range: -40 °C to +125 °C

• Photovoltaic Driver for High Voltage MOSFETs for Automotive Application

• Open Circuit Voltage: 7 V Typical at IF =10 mA

• Short Circuit Current: 5 µA Typical at IF =10 mA

• Logic Circuit Compatibility

• Switching Speed: 0.8 ms (TON), 0.04 ms (TOFF) Typical at IF = 10 mA, CL = 1 nF

• Configurable to wide portfolio of high voltage MOSFETs

• Galvanic Isolation

• High Input-to-Output Insulation Voltage

• Safety and Regulatory Approvals

– IEC/EN/DIN EN 60747-5-5 Maximum Working Insulation Voltage 1140 VPEAK

– 5000 VRMS for 1 minute per UL1577

– CSA Component Acceptance

Applications

• Battery Insulation Resistance Measurement/Leakage Detection

• BMS Flying Capacitor Topology for Sensing Batteries

• Solid State Relay Module
