The DLPC120ZXSQ1 Automotive Digital Micromirror Device (DMD) Display Controller is part of a chipset compatible with one of three DMDs (DLP3030-Q1, DLP3020-Q1, or DLP3021-Q1). The core DLPC120-Q1 logic accepts video inputs and formats the data for display on the DMD while controlling the RGB LEDs to create a live image.The DLPC120-Q1 is also responsible for controlling the DMD's power-down and power-up events based on external system control or temperature inputs from the DMD. With the microcontroller and external dimming circuit, the DLPC120-Q1 supports a wide dimming range of greater than 5000:1 for HUD applications.

Features

Compliant with AEC-Q100 for automotive applications

-40°C to 105°C ambient temperature rating2

Compatibility with three DMD devices

DLP3030-Q1: 0.3 WVGA S450

DLP3020-Q1 : 0.3 WVGA S247

DLP3021-Q1 : 0.3 WVGA S247

Video Input Interface

24-bit parallel (RGB888, RGB666 or RGB565)

60Hz frame rate

Input resolutions from QVGA to WVGA

Pixel clock up to 40MHz

Video processing

Image scaling

Programmable de-gamma curve

Border adjustment

Horizontal and vertical image flip

DMD Interface

78MHz DDR DMD interface

Consistent DMD data load and reset control Thermal operating range

Automatic DMD stop in case of power failure

DMD temperature management

External Memory Support

DDR2: 312MHz clock (624MHz data rate)

Serial Flash 39MHz clock

System Control

I2C communication interface

Programmable boot screen

DMD power and reset driver control

Flash-based programmable configuration

Test Support

Built-in test pattern generator

JTAG with boundary-scan support

Available in 216-pin, 1.0mm pitch BGA package

Applications

Large field of view and augmented reality flat panel displays (HUD)

Indoor projection displays and lighting

Automotive small lights

Digital instrument panel, navigation and infotainment windscreen displays

Dynamic ground projection
