The MSPM0L1304TDYYR microcontroller (MCU) is part of MSP's highly integrated, ultra-low power 32-bit MSPM0 MCU family. The cost-optimised MCUs integrate high-performance analogue peripherals, support an extended temperature range from -40°C to -40°C, and operate from 1.62 V to 3.6 V. Up to 64 Kbytes of embedded Flash program memory and up to 4 Kbytes of SRAM are available. The MCUs have a built-in, high-speed, on-chip oscillator with an accuracy of up to ±1.2%, eliminating the need for an external crystal.

Product Attributes

Core Processor: ARM® Cortex®-M0+

Core specification: 32-bit

Speed: 32 MHz

Connectivity: DALI, I2C, IrDA, LINbus, Smart Card, SMBus, SPI, UART/USART

Peripherals: Undervoltage Detect/Reset, DMA, POR, PWM, WDT

Number of inputs/outputs: 13

Program memory capacity 16KB (16K x 8)

Program memory type: Flash

RAM Size: 2K x 8

Supply Voltage (Vcc/Vdd): 1.62V ~ 3.6V 1.62V ~ 3.6V

Data Converter: A/D 6x12b SAR

Oscillator Type: External, Internal

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Package/Shell: Flat SOT-23-16, Variant SOT-23

Delivery range: 16-SOT-23-THIN

Applications

● Battery charging and management

● Power supply and power delivery

● Personal electronics

● Building and fire safety

● Networked peripherals and printers

● Grid infrastructure

● Smart metering

● Communication modules

● Medical and healthcare

● Lighting
