The PIC32MZ2064DAH169-I/6J family offers MPU-like performance with ease of design, an MCU for GUI design featuring 2MB of Flash and 640KB of SRAM, 32MB or 128MB of externally addressed DDR2 DRAM, an integrated graphics controller, graphics processor, 200 MHz speed, a 12-bit 18 MSPS ADC module (up to 45 analogue inputs), CAN and HS USB. MSPS ADC module (up to 45 analogue inputs), CAN and HS USB.

Product Features

200 MHz, MIPS32 microAptiv core

Dual-plane flash memory with real-time update support

12-bit, 18 MSPS, 45-channel ADC module

Memory management unit for optimised embedded OS execution

microMIPS mode with up to 35% code compression

CAN, UART, I2C, PMP, EBI, SQI and analogue comparators

SPI/I2S interface for audio processing and playback

Hi-Speed USB Device/Host/OTG

10/100 Mbps Ethernet MAC with MII and RMII interfaces

Cryptographic engine with RNG for data encryption/decryption and authentication (AES, 3DES, SHA, MD5 and HMAC)

Peripheral and memory area access control

Temperature range - 40°C to 85°C, - 40°C to 105°C (planned)

Operating voltage range 2.3V to 3.6V

2MB flash memory (plus 160KB boot flash)

640KB SRAM memory

microMIPS mode reduces code size by up to 35 per cent

Four 64-bit accumulators

Single-channel MAC, saturation maths and fractional maths

IEEE 754 compliant

Code-efficient (C and assembly) architecture

Multiple power management options to significantly reduce power consumption (VBAT, deep sleep, sleep and idle)

Deep sleep current: < 1µA (typical)

Integrated POR and BOR

Programmable high/low voltage detection (HLVD) on VDDIO and high voltage detection (HVD) on VDDR1V8

Programmable PLL and oscillator clock source

DDR2-specific PLL

Fail-safe clock monitor

Independent watchdog and deadlock timers

Fast wake-up and boot-up

Internal DDR2 SDRAM interface (up to DDR2-400), 32MB SDRAM on board

50 MHz SD/SDIO/eMMC bus interface

50 MHz External Bus Interface (EBI)

80 MHz Serial Quad Interface (SQI)

Peripheral Pin Selection (PPS) function enables functional remapping

Up to 8-channel hardware DMA with automatic data size detection

Six UART modules (25 Mbps): supports LIN 1.2 and IrDA protocols

Two 2.0B Active CAN modules with DeviceNet addressing support

Six 4-wire SPI modules (80 Mbps)

SQI configurable as additional SPI module (50 MHz)

Five I2C modules (up to 1 Mbaud) with SMBus support

Parallel Master Port (PMP)

Hardware real-time clock and calendar (RTCC) module

Nine 16-bit timer/counters (four 16-bit pairs combined into four 32-bit timers)

Nine input capture (IC) and nine output compare (OC)/PWM outputs

3-level graphics controller supporting up to 24-bit colour

High-performance 2D graphics processor (GPU)

Audio data communications: I2S, LJ, RJ, USB

Audio data control interfaces: SPI and I2C™

Audio Data Master Clock Fractional Clock Frequency, USB Sync

12-bit ADC Module:

18Msps rate with six sample and hold (S&H) circuits (five dedicated and one shared)

Up to 45 analogue inputs

Operates in sleep and idle modes

Multiple trigger sources

Six digital comparators and six digital filters

Two comparators with 32 programmable voltage references

Temperature sensor with ±2°C accuracy

Charge Time Measurement Unit (CTMU)

AEC-Q100 REVG (Level 2 -40oC to +105oC) (planned)

Class B safety vault, IEC 60730

Spare internal oscillator

In-circuit and in-application programming

4-wire MIPS® enhanced JTAG interface

Unlimited programs and 12 complex data breakpoints

IEEE 1149.2 (JTAG) boundary-scan compatible

Non-intrusive hardware-based instruction trace

MPLAB Harmony - PIC32 Software Development Framework

C/C++ compiler with native DSP/score and FPU support

TCP/IP, USB, graphics and mTouch middleware

MFi, Android and Bluetooth audio frameworks

Real-time operating system kernels, Express Logic ThreadX FreeRTOS, OPENRTOS, Micriµm, µC/OS and SEGGER embOS
