TPS1HA08EQPWPRQ1 - 40V, 8mΩ Single-Channel Smart High-Side Switch

Product Description

TPS1HA08EQPWPRQ1 is a single-channel smart high-side switch intended for use with 12-V automotive systems. The device integrates robust protection and diagnostic features to ensure output port protection even during harmful events like short circuits. It provides a high accuracy analog current sense that allows for improved diagnostics when driving varied load profiles.

Product Features

Single-channel smart high-side switch with 8-mΩ RON (TJ = 25°C)

Device temperature grade 1: –40°C to +125°C ambient operating temperature range

Withstands 40V load dump

Improve reliability through selectable current limiting

– Current limit set-point at 20 A or 80 A

– Overcurrent response of current clamping or instant shutdown

Analog sense output can be configured to accurately measure:

– Load current

– Supply voltage

– Device temperature

Provides FLT indication back to MCU

– Detection of open load and short-to-battery

Applications

Body control modules

Incandescent and LED lighting

Heating elements:

– Seat heaters

– Glow plug

– Tank heaters

Transmission control unit

Climate control

Infotainment display

ADAS modules
