CY8C4248FNI-BL543T is a scalable and reconfigurable platform architecture for a family of programmable embedded system controllers with an Arm® Cortex®-M0 CPU. It combines programmable and reconfigurable analog and digital blocks with flexible automatic routing.

Features

32-bit MCU subsystem

24-MHz Arm® Cortex®-M0 CPU with single-cycle multiply

Up to 256 KB of flash with read accelerator

Up to 32 KB of SRAM

2.4-GHz RF transceiver with Bluetooth® LE 4.2 support and 50-Ω antenna drive

Digital PHY

Link layer engine supporting master and slave modes

RF output power: –18 dBm to +3 dBm

RX sensitivity: –89 dBm

RX current: 16.4 mA

TX current: 15.6 mA at 0 dBm

Received Signal Strength Indication (RSSI): 1-dB resolution

Active mode: 1.7 mA at 3-MHz flash program execution

Deep-Sleep mode: 1.3 µA with watch crystal oscillator (WCO) on

Hibernate mode: 150 nA with RAM retention

Stop mode: 60 nA

LCD drive supported on all pins (common or segment)

Operates in Deep-Sleep mode with four bits per pin memory

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
