LX34070T-H/ST is an inductive position sensor IC for high-speed and noise-immune automotive and industrial application and extremely flexible for other applications. The two output signals that represent the absolute position can be configured as single ended for reduced pin count or differential to maximize noise immunity in remote applications.

Product Attributes

Technology: Inductive

Output Signal: Cosine, Sine

Actuator Type: Inductive Target

Voltage - Supply: 4.5V ~ 5.5V

Mounting Type: Surface Mount

Termination Style: Gull Wing

Operating Temperature: -40°C ~ 150°C

Package / Case: 14-TSSOP (0.173", 4.40mm Width)

Supplier Device Package: 14-TSSOP

Product Features

AEC-Q100 Grade 0 Certification

ISO26262 ASIL C(D) SEOOC Compliant

Built-in Oscillator for Driving Primary Coil

Two Independent Analog Channels With Demodulation

Automatic Gain Control Maximizes Resolution over Large Target Air gaps Ranges

4.5V to 5.5V Input Range with Protection Up to 18V

Differential Output Buffers with Accurate Common-Mode Level and Protection Circuitry Against Output Shorts

Calibration Through VIN or GPIO

Detection of Faults at the Exciter Coil Pins and Receive Coil Pins

Power Supply and Ground Loss Detection

-40°C to 150°C Operation
