The HMC1501 is a high-precision magnetoresistive position sensor introduced by Honeywell, featuring an 8-pin SOIC package. It is primarily used for measuring magnetic field direction angles and is suitable for non-contact displacement detection. This sensor is based on the magnetoresistive effect, capable of measuring an angle range of ±45°, with a resolution as high as 0.07°, and supports a supply voltage of 3V to 5V, outputting a full-scale signal of 120mV (when powered by 5V).

The HMC1501 employs a single magnetoresistive bridge structure, operates in a magnetically saturated state (>80 Gauss), and offers advantages such as vibration resistance and temperature drift resistance, making it suitable for applications in industrial automation, automotive electronics, medical devices, and other fields.

HMC1501 Specifications

Measurement Range: ±45° (angle)

Resolution: <0.07°

Supply Voltage: 3V to 5.5V

Output Signal: Analogue (Wheatstone bridge, 120 mV @5 V)

Linear Distance: 8 mm (expandable)

Bandwidth: Up to 5 MHz

Package Size: 5 mm × 4 mm × 1.2 mm (SOIC-8)

Operating Temperature: -40°C to +85°C

Magnet Compatibility: Alnico/ceramic magnets (No rare earth magnets required)

HMC1501 Key Features

High-precision measurement

0.07° resolution, suitable for precision angle detection.

Absolute position output, no encoder index required.

Strong anti-interference capability

Unsensitive to temperature changes, suitable for wide temperature environments.

Resistant to mechanical vibration, suitable for automotive/industrial applications.

Low power consumption & compact size

3V low voltage operation, suitable for portable devices.

5mm × 4mm package, suitable for compact designs.

Non-contact detection

No mechanical wear, long service life.

Supports 8mm linear distance, expandable with multiple sensors.
