Description: ARM® Cortex®-M4 series microcontroller IC 32-bit single core 72MHz 256KB (256K x 8) Flash 100-LQFP (14x14)

Specification

Core processor ARM® Cortex®-M4

Core Specifications 32-bit single core

Speed 72MHz

Connectivity CANbus, I²C, IrDA, LIN, SPI, UART/USART, USB

Peripherals DMA, I²S, POR, PWM, WDT

Number of I/Os 87

Program storage capacity 256KB (256K x 8)

Program Memory Type Flash

EEPROM capacity -

RAM size 40K x 8

Voltage - Power Supply (Vcc/Vdd) 2V ~ 3.6V

Data Converter A/D 39x12b; D/A 2x12b

Oscillator Type Internal

Operating temperature -40°C ~ 85°C (TA)

Mounting Type Surface Mount

Package/Enclosure 100-LQFP

Vendor Device Package 100-LQFP (14x14)
