ST25DV64KC-IE6T3 is Dynamic NFC/RFID tag IC with 64Kbit EEPROM, fast transfer mode capability and optimized I2C. It feature two interfaces: the first one is an I²C serial link that can be operated from a DC power supply, the second one is an RF link activated when the device acts as a contactless memory powered by the received carrier electromagnetic wave.

Product Features

I2C interface

• Two-wire I2C serial interface supports 1MHz protocol

• Single supply voltage: 1.8 V to 5.5 V

• Multiple byte write programming (up to 256 bytes)

• Configurable I2C slave address

Contactless interface

• Based on ISO/IEC 15693

• NFC Forum Type 5 tag certified by the NFC Forum

• Supports all ISO/IEC 15693 modulations, coding, sub-carrier modes and data rates

• Custom fast read access up to 53 kbit/s

• Single and multiple blocks read (same for Extended commands)

• Single and multiple blocks write (up to four) (same for Extended commands)

• Internal tuning capacitance: 28.5 pF

Memory

• Up to 64-Kbit of EEPROM (depending on version)

• I2C interface accesses bytes

• RF interface accesses blocks of 4 bytes

Fast transfer mode

• Fast data transfer between I2C and RF interfaces

• Half-duplex 256 bytes dedicated buffer
