New and original sensor PIR PYQ 1548/7659 low power TO-5 variant, 4 leads

New and original sensor PIR PYQ 1548/7659 low power TO-5 variant, 4 leads

Source:our siteTime:2022-11-02Views:

Mingjiada supplies new original sensors PIR "PYQ 1548/7659" low power TO-5 variant, 4 leads

Mingjiada supplies new original sensors PIR "PYQ 1548/7659" low power TO-5 variant, 4 leads


The PYQ 1548 is a serial opposed format four-element detector based on pyrolytic ceramics. The signal is converted to a digital value using Sigma-Delta and DSP technology. A configurable motion detection unit is implemented. Once motion is detected, an interrupt is sent to the host system. Putting the host system to sleep will achieve an overall ultra-low power consumption. All data can be accessed from the host system for advanced signal analysis using your own detection criteria.


Specification

Sensor Type PIR (Passive Infra-Red)

Sensing distance -

Output type Digital

Voltage - Supply 1.8V ~ 3.6V

Trigger type Internal

Characteristics Low Power

Package/Housing TO-5 variant, 4 lead, lens top metal pot

Operating Temperature -

Detection Mode -


Applications

- Medium range motion detection (with lens)

- Energy saving applications

- Intruder alarms

- Ceiling mounted applications

- Battery operation
