Kingston's discrete Low Power Double Data Rate 4 (LPDDR4) dynamic random access memory (DRAM) is designed to meet the needs of embedded applications and offers high-speed options with lower power consumption. LPDDR4 is a DRAM designed for low power consumption in mobile devices such as smartphones, tablets, and laptops. It is a significant improvement over its predecessor (LPDDR3) in terms of data transfer rate, energy efficiency, and overall performance. LPDDR4 operates at higher frequencies for faster data access, better multiprocessing, and less power consumption, which is critical to extending the battery life of portable devices. This memory technology combines features such as on-chip Terminal (ODT), deep power saving mode, and more efficient signal interface to reduce energy consumption without compromising performance, making it ideal for modern mobile computing platforms.

Product: D0811PM2FDGUK-U

Type: SDRAM-LPDDR4

Storage capacity: 8 Gbit

Data bus width: 64 bit

Max clock frequency: 1.6GHz

Package/housing: FBGA-200

Organization: 64 M x 8

Access time: 3.5 ns

Operating temperature: -25 °C to + 85°C

Features:

Low power consumption

Update per Bank

Partial Array Automatic Reorganization (PASR)

Bank mask

Sectional mask

Automatic temperature compensation Automatic rearrangement (ATCSR) via built-in temperature sensor

Supports all Bank automatic realignment and targeted per Bank automatic realignment

Double data rate architecture; There are two data transfers per time cycle

Differential pulse input: CK_t and CK_c

Bidirectional differential data strobes: DQS_t and DQS_c

Enter commands on the positive and negative edges of CK_t; Refer to DQS_t edge data and data masks

DMI pins support write data masks and DBIdc functionality

Commercial grade operating temperature range: 0°C to +70°C

Industrial grade operating temperature range: -40°C to +85°C

Applications:

Smartphones and tablets

A handheld device

Laptops and slim laptops

Wearable device

CARS

Virtual Reality (VR) and Augmented Reality (AR)

Digital cameras and camcorders

Network equipment

Industrial and embedded systems
