ISSI's flash memory devices are ideal for performance-oriented applications that require high reliability.

ISSI's IS34ML and IS34MW family of NAND products complement serial and parallel NOR products for the embedded market. The ML (3.0V) series and MW (1.8V) series SLC NAND devices are available in densities of 1Gb, 2Gb and 4Gb, respectively.

SLC NAND flash devices are ideal for performance-oriented applications that require high reliability. SLC Each storage unit stores one bit of data and provides fast read and write functions. These products are suitable for systems that require 1 - or 4-bit ECC algorithms and offer 100 K cycle durability and a 10-year retention period.

Product: IS34ML04G168-BLI

Type: NAND Flash

Package/box: VFBGA-63

Storage capacity: 4 Gbit

Interface type: : Parallel

Organization: 512 M x 8/256 M x 16

Timing type: : Asynchronous

Data bus width: 8 bit, 16 bit

Supply voltage: 2.7V to 3.6V

Power supply current - Max. : 30 mA

Operating temperature: -40 °C to + 85°C

Active reading current (Max.) : : 30 mA

Features:

Supply voltage:

VCC: 2.7V to 3.6V (IS34ML series)

VCC: 1.7V to 1.95V (IS34MW series)

Flexible x8 or x16 options

Uniform high cost block

Block erase time: 3 ms (typical)

Automatic read operation

Hardware data protection

100 K programming/erase cycle

Data retention time: 10 years

Supports 1-bit or 4-bit ECC per 512 bytes

Industrial temperature range: -40°C to +85°C

Extended temperature range: -40°C to 105°C

Industry standard package: 48-pin TSOP and 63-pin (9 mm x 11 mm BGA)

Related products:

IS34ML04G088-TLI

IS34ML04G088-BLI

IS34ML04G168-BLI

Applications:

Automotive infotainment

Instrument cluster

ADAS

Industrial instrument

Industrial sensor

M2M

POS terminal

Intelligent measurement

Game machine

printer

Digital camera

Digital television

Set-top box
