Supply [NXP] IW612UK/A1IZ Dual-Band 1x1 Wi-Fi® 6 + Bluetooth® 5.4 + 802.15.4 Tri-Radio Single-Chip

Supply [NXP] IW612UK/A1IZ Dual-Band 1x1 Wi-Fi® 6 + Bluetooth® 5.4 + 802.15.4 Tri-Radio Single-Chip

Source:our siteTime:2024-08-14Views:

Shenzhen Mingjiada Electronics Co., Ltd. Supply [NXP] IW612UK/A1IZ Dual-Band 1x1 Wi-Fi 6 + Bluetooth 5.4 + 802.15.4 Tri-Radio Single-ChipIW612UK/A1IZ - Product Description:IW612UK/A1IZ is a highly integrated 2.4/5 GHz dual-band 1x1 Wi-Fi 6, Bluetooth/…

Shenzhen Mingjiada Electronics Co., Ltd. Supply [NXP] IW612UK/A1IZ Dual-Band 1x1 Wi-Fi® 6 + Bluetooth® 5.4 + 802.15.4 Tri-Radio Single-Chip


IW612UK/A1IZ - Product Description:

IW612UK/A1IZ is a highly integrated 2.4/5 GHz dual-band 1x1 Wi-Fi 6, Bluetooth/Bluetooth Low Energy 5.4 and 802.15.4 tri-radio single-chip solution. IW612 includes a full-feature Wi-Fi subsystem powered by NXP’s 802.11ax (Wi-Fi 6) technology bringing higher throughput, better network efficiency, lower latency and improved range over previous generation Wi-Fi standards.


IW612UK/A1IZ - Product Features:

Wi-Fi Key Features

- 1x1 2.4/5 GHz, up to 80 MHz channel

- UL/DL MU-MIMO and OFDMA

- Target Wake Time, Dual Carrier Modulation, Extended Range

- 802.11az accurate ranging

- WPA3 security

- SDIO 3.0 host interface

Bluetooth Key Features

- Supports Bluetooth 5.2 features

- Bluetooth 5.4 certified

- Integrated high power PA up to +20 dBm transmit power

- Full featured Bluetooth baseband

- SCO/eSCO links with hardware accelerated audio signal processing

- Bluetooth LE 2 Mbit/s, Long Range, Advertising Extensions

- LE Audio with Isochronous channels

- UART host interface

802.15.4 Key Features

- IEEE 802.15.4-2015 compliant supporting Thread in 2.4 GHz band

- Integrated high power PA up to +20 dBm transmit power

- Shared transmitter and antenna pin with Bluetooth

- Simultaneous receive with Bluetooth

- SPI host interface


IW612UK/A1IZ - Internal Block Diagram:



If you have a requirement, please call Mr. Chen for advice at:

Tel: +86 13410018555

E-mail: sales@hkmjd.com

Home page URL: www.hkmjd.com
