The AM6251ASGGHAALWR device is a human-computer interaction SoC with Arm® Cortex®-A53 based edge AI and full HD dual display.

Overview

TI's low-cost AM62x Sitara™ MPU family of application processors is built specifically for Linux® application development. With scalable Arm® Cortex®-A53 performance and embedded features, such as dual display support and 3D graphics acceleration, as well as a broad set of peripherals, AM62x devices are well suited for a wide range of industrial and automotive applications, while also providing intelligent functionality and an optimized power architecture.

Some of these applications include:

• Industrial HMI

• Charging stations for electric vehicles

• Non-contact building access control

• Driver monitoring system

The 13mm x 13mm package (ALW) model of the AM62x Sitara™ processor is an industrial-grade processor, while the 17.2mm x 17.2mm package (AMC) model meets the AEC-Q100 automotive standard. Industrial and automotive functional safety requirements can be met with an integrated Cortex-M4F core and dedicated peripherals that are isolated from the rest of the AM62x processor.

Specifications of AM6251ASGGHAALWR:

Core: ARM Cortex A53, ARM Cortex M4F

Number of cores: 2 cores

Data bus width: 64 bit

Maximum clock frequency: 400 MHz, 1.4 GHz

Package/housing: FCCSP-425

L1 Cache instruction memory: 32 kB

L1 Cache data storage: 32 kB

Working power supply voltage: 750 mV, 850 mV

Series: AM625

Installation style: SMD/SMT

Minimum operating temperature: -40 °C

Maximum operating temperature: + 105°C

Package: Reel

Encapsulation: Cut Tape

Trademark: Texas Instruments

Data RAM size: 4 GB, 8 GB

I/O voltage: 1.1V, 1.2V, 1.8V, 3.3V

Description type: Floating Point

Interface type: CAN, Ethernet, QSPI, SPI, UART, USB

L2 cache instruction/data memory: 512 kB

Storage type: DDR4, LPDDR4

Humidity sensitivity: Yes

Number of input/output terminals: 170 I/O

Number of timers/counters: 12 Timer

Product Type: Microprocessors-MPU

AM62x Sitara™ Processor applications:

Human Machine Interface (HMI)

• Retail automation

• Driver Monitoring System (DMS/OMS)/ In-Vehicle Monitoring (ICM)

• Telematics Control Unit (TCU)

• 3D point cloud

Vehicle-to-infrastructure (V2V)/ Vehicle-to-Vehicle (V2X)

• 3D reconfigurable automotive instrument set

• Appliance user interface and connectivity

• Medical equipment
