Model: S9KEAZN64AMLHR
Year: 21+
Package: LQFP64

Kinetis ® EA Series 32-bit Arm ® Cortex ® MCU is widely used in automotive and industrial applications with high quality requirements and long-term supply assurance requirements. The Kinetics EA series is an entry-level product of the extensive Arm ecological cooperation system, and has the following functions:
• Low power ARM Cortex-M0+core and 8 – 128 KB embedded flash memory
• It has excellent EMC/ESD compatibility, can adapt to high temperature environment, and has low radiation emissions
• Provide scalable, stable and reliable high-performance solutions for cost sensitive automotive applications
• Have a wealth of reference designs, tools and application notes, which can help you speed up design and development and speed up product launch.

Specifications
Core processor: ARM ® Cortex ®- M0+
Kernel specification: 32-bit single core
Speed: 40MHz
Connection capacity: I ² C，LINbus，SPI，UART/USART
Peripherals: LVD, POR, PWM, WDT
Number of I/Os: 57
Program storage capacity: 64KB (64K x 8)
Program memory type: flash memory
EEPROM capacity: 256 x 8
RAM size: 4K x 8
Voltage power supply (Vcc/Vdd): 2.7V~5.5V
Data converter: A/D 16x12b
Oscillator type: internal
Operating temperature: - 40 ° C~125 ° C (TA)
Installation type: surface mount
Package/enclosure: 64-LQFP
Supplier device package: 64-LQFP (10x10)

Application
Infotainment connection module
Parking aid
DC/BLDC motor control
Electric parking brake
Tire pressure monitoring system
Motorcycle CDI/EFI
Battery management
Pump/Fan Controller
Passive entry button activated
Ambient lighting
BCM/HVAC
Window/door/skylight
Seat/rearview mirror/wiper
Anti theft system
Power system supporting chip
Common sensor node
