[Supply Original] RAA2116514GNP (Renesas) Integrated 60V, 5A Synchronous Buck Regulator

Shenzhen Mingjiada Electronics Co., Ltd. — Long-term supplier of 【Renesas】RAA2116514GNP (buck regulator) 60V, 5A, low quiescent current integrated switch-mode regulator.

Product Details:

The RAA2116514GNP is an integrated 60V 5A synchronous buck regulator featuring a constant on-time (COT) control system. The RAA2116514GNP supports a wide input voltage range from 4.5V to 60V and an adjustable output voltage (0.8V to maximum duty cycle * VIN).

Product Model: RAA2116514GNP

Package: QFN-28

Type: Buck Regulator

Product Image:

RAA2116514GNP also features very low quiescent current, typically 10μA at 24V input. The adopted modulation scheme achieves high efficiency across all output load levels, particularly under light load conditions. RAA2116514GNP provides comprehensive protection features, including under-voltage lockout, overcurrent (positive and negative), overvoltage, and over-temperature protection.

RAA2116514GNP Specifications:

Product Type: Switching Regulator

Mounting Style: SMD/SMT

Package/Case: QFN-28

Topology: Buck

Output Voltage: 800 mV to 60 V

Output Current: 5 A

Number of Outputs: 1 Output

Input Voltage - Minimum:    4.5 V

Input Voltage - Maximum:    60 V

Quiescent Current:    19 uA

Switching Frequency:    565 kHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Input Voltage:    4.5 V to 60 V

Operating Power Supply Current:    1 uA

RAA2116514GNP — Functional Block Diagram:

[Mingjiada Electronics] Long-term supply of RAA2116514GNP. For the RAA2116514GNP buck regulator datasheet, samples, or price inquiries, please contact Mingjiada Electronics:
