ADI VCO Oscillators HMC506LP4ETR GaAs InGaP HBT MMIC VCO Oscillator

ADI VCO Oscillators HMC506LP4ETR GaAs InGaP HBT MMIC VCO Oscillator

Source:our siteTime:2024-07-19Views:

ADI VCO Oscillators HMC506LP4ETR GaAs InGaP HBT MMIC VCO OscillatorProduct DescriptionHMC506LP4ETR is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO with an integrated resonator, negative resistance device, varactor diode, and buffer am…

ADI VCO Oscillators HMC506LP4ETR GaAs InGaP HBT MMIC VCO Oscillator


Product Description

HMC506LP4ETR is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO with an integrated resonator, negative resistance device, varactor diode, and buffer amplifier.


Features

Pout: +14 dBm

Phase Noise: -103 dBc/Hz @100 KHz

No External Resonator Needed

Single Supply: +3V @ 77 mA

QFN Leadless SMT Package, 16 mm2


Applications

VSAT Radio

Point-to-Point/Multi-point Radio

Test Equipment & Industrial Controls

Military End-Use
