Supply, Recycle [Microchip] KSZ9031RNXIC Gigabit Ethernet Transceiver with RGMII Interface

Supply, Recycle [Microchip] KSZ9031RNXIC Gigabit Ethernet Transceiver with RGMII Interface

Source:our siteTime:2024-06-05Views:

Shenzhen Mingjiada Electronics Co., Ltd. Supply, Recycle [Microchip] KSZ9031RNXIC Gigabit Ethernet Transceiver with RGMII InterfaceProduct OverviewsKSZ9031RNXIC is a completely integrated triple-speed (10BASE-T/100BASE-TX/1000BASE-T) Ethernet physical…

Shenzhen Mingjiada Electronics Co., Ltd. Supply, Recycle [Microchip] KSZ9031RNXIC Gigabit Ethernet Transceiver with RGMII Interface


Product Overviews

KSZ9031RNXIC is a completely integrated triple-speed (10BASE-T/100BASE-TX/1000BASE-T) Ethernet physicallayer transceiver for transmission and reception of data on standard CAT-5 unshielded twisted pair (UTP) cable. The KSZ9031RNX provides the Reduced Gigabit Media Independent Interface (RGMII) for direct connection to RGMII MACs in Gigabit Ethernet processors and switches for data transfer at 10/100/1000 Mbps.


Features

• Single-Chip 10/100/1000 Mbps Ethernet Transceiver Suitable for IEEE 802.3 Applications

• RGMII Timing Supports On-Chip Delay According to RGMII Version 2.0, with Programming Options for External Delay and Making Adjustments and Corrections to TX and RX Timing Paths

• RGMII with 3.3V/2.5V/1.8V Tolerant I/Os

• Auto-Negotiation to Automatically Select the Highest Link-Up Speed (10/100/1000 Mbps) and Duplex (Half/Full)

• On-Chip Termination Resistors for the Differential Pairs

• Jumbo Frame Support up to 16 KB

• 125 MHz Reference Clock Output

• Wake-On-LAN (WOL) Support with Robust Custom-Packet Detection


Target Applications

• Network Attached Storage (NAS)

• Network Server

• Gigabit LAN on Motherboard (GLOM)

• Broadband Gateway

• Gigabit SOHO/SMB Router

• Triple-Play (Data, Voice, Video) Media Center

• Industrial Control

• Automotive In-Vehicle Networking


If you have a requirement, please call Mr. Chen for advice at:

Tel: +86 13410018555

E-mail: sales@hkmjd.com

Home page URL: www.hkmjd.com
