Shenzhen Mingjiada Electronics Co., Ltd. currently supplies CY14V101QS-BK108XQ high-performance nvSRAM memory chips on a long-term and stable basis.

Product Description:

The Cypress CY14V101QS-BK108XQ is a 1-Mbit (128K×8) Quad SPI nvSRAM chip featuring high reliability, fast read/write speeds, and non-volatile storage capabilities. It is widely used in high-demand applications such as automotive electronics, industrial control, and communication equipment.

Product Features:

High-density storage: 1-Mbit (128K×8) storage capacity to meet the needs of various complex application scenarios.

High-speed interface: Supports clock frequencies up to 108MHz, with read/write speeds reaching 54Mbps.

Multiple interface modes: Supports single-wire SPI, dual-wire DPI, and quad-wire QPI modes for flexible adaptation to different systems.

High reliability: Supports unlimited read/write and recall (RECALL) operations. The non-volatile storage unit (SONOS FLASH Quantum Trap) can perform up to 1 million store (STORE) operations.

Data protection: Features hardware write protection (via the WP pin) and software write protection (via the write disable command), with support for block protection functionality.

Low power mode: Average current in sleep mode is 280µA (85°C), and average current in hibernation mode is 8µA (85°C).

Wide operating temperature range: Extended industrial-grade temperature range from -40°C to 105°C, suitable for various harsh environments.

Package type: 24-pin lead-free ball grid array (FBGA), space-saving.

Technical specifications:

Memory type: Non-volatile nvSRAM

Storage capacity: 1 Mbit (128K × 8)

Interface: Quad SPI

Clock frequency: Up to 108MHz

Operating voltage:

Core voltage VCC: 2.7V to 3.6V

I/O voltage VCCQ: 1.71V to 2.0V

Operating temperature:

Extended industrial-grade: -40°C to 105°C

Industrial-grade: -40°C to 85°C

Package: 24-FBGA

Application Scenarios

CY14V101QS-BK108XQ is suitable for applications requiring high reliability, fast read/write performance, and non-volatile storage, including but not limited to:

Industrial Control: Motor control, sensor data acquisition.

Consumer Electronics: Home appliances, battery management.

Automotive electronics: Body control, instrument panels, and displays.

Internet of Things (IoT): Smart home, wireless sensor nodes.

Medical electronics: Portable medical devices, health tracking devices.
