Shenzhen Mingjiada Electronics Co., Ltd. offers the Microchip LAN9500AI-ABZJ USB 2.0 to 10/100 Ethernet controller in stock. This chip is a high-performance, low-cost USB-to-Ethernet bridge chip widely used in embedded systems, industrial control, sma…
Shenzhen Mingjiada Electronics Co., Ltd. offers the Microchip LAN9500AI-ABZJ USB 2.0 to 10/100 Ethernet controller in stock. This chip is a high-performance, low-cost USB-to-Ethernet bridge chip widely used in embedded systems, industrial control, smart home, and network equipment applications.
Product Overview
The LAN9500AI-ABZJ is a high-performance, low-power USB 2.0 to 10/100 Ethernet bridge controller introduced by Microchip, packaged in a 56-QFN (8x8mm) package, featuring the following core characteristics:
Interface Type: USB 2.0 (480Mbps) and 10/100 Base-T/TX PHY
Operating Voltage: Multi-voltage support (1.2V, 2.5V, 3.3V)
Operating Temperature Range: -40°C to 85°C, suitable for industrial-grade applications
Low-Power Design:
SUSPEND1 Mode: Only 27.5mW (LAN9500AI version)
Operating Mode (100BASE-TX Full-Duplex): 367mW
Advanced Power Management: Supports IEEE 802.3az Energy Efficient Ethernet (EEE) standard
Flexible Physical Layer Interface: Supports RGMII, RMII, MII, and other configurations
Technical Specifications
Interface Type: USB 2.0, 10/100 Base-T/TX PHY
Operating Voltage: 1.2V, 2.5V, 3.3V
Operating Temperature Range: -40°C to 85°C
Package Type: 56-QFN (8x8)
Maximum Data Rate: 100 Mbps
Target Applications
• Embedded Systems
• Set-Top Boxes
• Personal Video Recorders (PVRs)
• Consumer electronics devices
• Network printers
• USB port expanders
• Standalone USB-to-Ethernet adapters
• Test instruments
• Industrial applications
Purchasing Information
• Model: LAN9500AI-ABZJ
• Brand: Microchip Technology
• Year: 22+
• Package: 56-QFN (8x8mm)
• Packaging: Tray (260 pcs/tray)
Contact Information:
Contact Person: Mr. Chen
Phone: +86 13410018555
Email: sales@hkmjd.com
Address: Room 1239-1241, Xinyazhou Guoli Building, Zhenzhong Road, Futian District, Shenzhen City, Guangdong Province
Website: www.hkmjd.com
