Overview:

The ATWINC3400 SPI+UART to Wi-Fi and Bluetooth Low Energy (BLE) modules are designed to quickly and easily add wireless connectivity to Internet of Things (IoT) applications. The ATWINC3400 module is an ideal addition to existing microcontroller (MCU) solutions, providing Wi-Fi and BLE networking capabilities via a SPI-to-Wi-Fi interface. The ATWINC3400 can be connected to any Microchip PIC or SAM MCU with very low resource requirements.

The most advanced mode of the ATWINC3400 is single-stream 1 x 1 802.11n mode. The ATWINC3400 features fully integrated power amplifier, LNA, switching, and power management capabilities. The ATWINC3400 also features an on-chip processor and integrated flash memory for system software, with built-in coexistence mechanisms for parallel Wi-Fi and BLE functions. The only external clock source required for the ATWINC3400 is a high-speed crystal or oscillator.

Microchip technology ATWINC3400 SPI+UART to Wi-Fi and BLE modules can be used for external antennas with integrated chip antennas or micro U.F.L connectors. Both models have a compact 22.43mm x 14.73mm form factor.

ATWINC3400-MR210UA142

ATWINC3400-MR210CA143

ATWINC3400-MR210CA143-T

ATWINC3400-MR210UA143-T

ATWINC3400-MR210CA142

ATWINC3400-MR210CA142-T

ATWINC3400-MR210CA131

ATWINC3400-MR210UA131

ATWINC3400-MR210CA122

Applications:

Internet of Things application

Intelligent electrical apparatus

Health care

Home automation

Consumer electronics

Industrial automation

Mobile application

Features:

IEEE 802.11b /g/n 20 MHz (1x1) Wireless networking and Bluetooth 5

Network functions :TCP, UDP, DHCP, ARP, HTTP, SSL, and DNS

Supported security protocols :WPA/WPA2 Personal Edition, WPA2 Enterprise Edition (firmware version 1.31 or later), TLS, SSL

Bluetooth 5 authentication

Certified agents in the United States, Canada, Europe, Japan, Korea, China, India and Taiwan

Single spatial stream in 2.4GHz ISM band

Integrated PA and T/R switches

Superior sensitivity and range with advanced PHY signal processing

Operating temperature range is -40℃ to +85℃

The integrated network IP stack minimizes host CPU requirements

The on-chip network stack for offloading the MCU

Class 2 transmission and adaptive frequency hopping

Compact 22.4mm x 14.7mm form factor
