Mingjiada Electronics Supplies TI TCAN1042HVDR: Enabling High-Speed Reliable CAN FD Communications

Product Description

The TCAN1042HVDR is a high-speed Controller Area Network (CAN) transceiver that is fully compliant with the ISO 11898-2 (2016) standard. Designed to meet the stringent bandwidth and reliability requirements of modern in-vehicle networks and industrial applications, it is perfectly suited to support flexible data rate (CAN FD) communications up to 5 Mbps. Available in a small SOIC-8 package (TCAN1042HVDR), the device integrates several advanced fail-safe features to ensure robust communication in harsh electrical environments.

TCAN1042HVDR Core Features

High-Speed CAN FD Support: Fully compatible with legacy CAN and high-speed CAN FD protocols, the TCAN1042HVDR delivers data rates up to 5 Mbps, significantly increasing network throughput.

Enhanced Fail-Safe Protection: The TCAN1042HVDR provides robust protection mechanisms, including:

Bus pin short-circuit protection against ±58V DC power supply

Resistance to ±±40V automotive electrical transients (compliant with ISO 7637-3)

Bus pin ground-fail protection (when VSUP is lost)

Thermal shutdown protection

Dominant timeout protection (TXD DTO)

Fail-safe receiver input ( Fail-safe receiver input (ensures RXD output is high when bus is idle or floating)

Low Power Management: Supports standby mode (remote wake-up detection) and sleep mode (very low quiescent current) to effectively reduce system power consumption, especially for battery-powered or power-sensitive applications.

High electromagnetic compatibility (EMI) and immunity (EMS): Excellent electromagnetic performance design to reduce interference and ensure signal integrity.

TCAN1042HVDR Key Specifications

Supply Voltage Range: 4.5V to 5.5V

Operating Temperature Range: -40°C to +150°C (meets AEC-Q100 Grade 1)

Maximum Data Rate: 5 Mbps (CAN FD)

Bus Failure Protection: ±58V DC (CANH, CANL)

IEC ESD Protection: ±8 kV ( CANH, CANL) - IEC 61000-4-2

Package: SOIC-8 (HVSSOP-8)

Conformity: ISO 11898-2:2016, ISO 7637-3, SAE J2962-2

TCAN1042HVDR Typical Application Areas

Thanks to its high speed, high reliability and wide temperature range, the TCAN1042HVDR is used in a wide range of applications in the following areas:

Automotive Electronics:

Body Control Modules (BCM)

Advanced Driver Assistance Systems (ADAS)

Powertrain Systems

Infotainment Systems

Electric Vehicle Battery Management Systems (BMS)

Gateway Modules

Industrial Automation:

Industrial Control Industrial Automation: Industrial Control Networks (PLC, DCS)

Factory Automation Equipment Communication

Motor Control

Robotics Control

Building Automation Systems

Transportation: Heavy Vehicle, Construction Machinery Control Systems.

Other: need high-speed, reliable CAN communication test and measurement equipment.

Mingjiada Electronics has been supplying original TCAN1042HVDR high speed CAN transceiver for a long time, welcome to contact us for detailed product information and quotation.
