Shenzhen Mingjiada Electronics supplies genuine Amphenol Mini MSD plugs MINI-MSDM250 automotive connectors (with 250 A fuse)

1. Product Description

The MINI-MSDM250 is an Amphenol Mini MSD series male connector featuring an integrated 250 A fast-acting fuse, specifically designed for the ‘one-button safe power disconnection’ of high-voltage battery systems in electric vehicles (EVs) and plug-in hybrid electric vehicles (PHEVs). Its compact flange panel mounting structure allows for quick insertion into the corresponding female socket, forming a high-voltage interlocked connection with IP67/IP69K protection ratings. Maintenance personnel can disconnect the high-voltage circuit in 5 seconds without tools, ensuring maintenance safety.

2. Core Features

• Rated current: 250 A (continuous)

• Rated voltage: 690 V AC / 1000 V DC

• Built-in fuse: 250 A gR fast-acting, replaceable with 200-400 A ratings

• Safety mechanisms: Two-stage lever + HVIL high-voltage interlock, signal disconnection followed by main circuit disconnection

• Protection rating: IP67 (mated state), optional IP69K

• Operating temperature: -40 °C to +125 °C

• Mating cycles: ≥100 times

• Certifications: LV215 / USCAR-2 / USCAR-37 / AEC-Q200 (Fuse)

3. Specification Parameters

Pole Count: 1 (single-pole)

Contact Resistance: ≤ 0.25 mΩ

Installation Method: Panel-mounted plug-in

Mechanical Holding Force: ≥ 200 N

Fuse Dimensions: 32 mm × 6.3 mm

Housing Colour: Orange (high-voltage warning)

Weight: Approximately 285 g

4. Typical Applications

• Power battery pack maintenance window

• High-voltage busbar maintenance disconnect in energy storage cabinets

• Quick-change battery modules in charging stations

• On-board PDU/DC-DC maintenance safety switch

5. Mingjiada Electronics' Inventory Advantages

• Long-term inventory of ≥ 10,000 pieces in dual temperature-controlled warehouses in Shenzhen and Hong Kong

• Supports orders starting from 1 piece, with same-day SF Express shipping

Contact Information

Phone: +86 13410018555 (Mr. Chen)

Email: sales@hkmjd.com

Website: www.hkmjd.com
