Mingjiada Electronics offers Amphenol electric vehicle connectors Mini MSD plug MINI-MSDM350 (with 350 A fuse)

MINI-MSDM350 Product Description

The MINI-MSDM350 is an Amphenol high-voltage miniature manual service disconnect (Mini MSD) plug specifically designed for plug-in hybrid electric vehicles (PHEVs) and electric vehicles (EVs). It features an integrated 350 A fuse for safe maintenance disconnection of high-voltage battery systems, ensuring operator safety and preventing short-circuit risks.

MINI-MSDM350 Core Features

High Current/High Voltage Support

Rated Current: 350A (continuous), with an integrated 350A gR fast-acting fuse, compatible with 200–400A ratings.

Rated Voltage: 690V AC / 1000V DC, suitable for 800V high-voltage platform electric vehicles.

Withstand voltage test: 3500V AC / 1 minute, compliant with industrial-grade electrical safety standards.

Safety Protection Mechanisms

High-voltage interlock circuit (HVIL): Disconnects the HVIL signal before opening high-voltage contacts to prevent arc risks.

Two-stage lever design: Press-and-rotate two-step unlocking to prevent accidental operation, with insertion/removal force ≤ 50N.

Fuse Protection: A 350A fuse prevents overload damage, enhancing system safety.

Industrial-Grade Reliability

Protection Rating: IP67 & IP6K9K (mated state), dustproof and waterproof, suitable for harsh environments.

Operating Temperature: -40°C to +125°C, suitable for extreme climate conditions.

Mechanical Life: ≥ 50 insertion/removal cycles, meeting frequent maintenance requirements.

Compact design

Dimensions: 91mm (width) × 73.5mm (height), smaller than standard MSD, saving installation space.

Installation method: Panel mount, compatible with MINI-MSDF series sockets.

Housing material: High-temperature resistant PA66 + glass fibre reinforced, with metal latches for reinforcement.

Typical Applications for MINI-MSDM350

Battery packs for pure electric vehicles (BEVs) – main positive/main negative MSD maintenance ports.

Plug-in hybrid electric vehicles (PHEVs) – high-voltage distribution units (BDUs).

Commercial vehicles/heavy-duty trucks – 800V high-voltage platforms for energy storage systems.

Battery swapping stations/energy storage cabinets – DC bus safety switches.

Fuel cell systems – high-voltage emergency disconnect points.
