Mingjiada Electronics Hot-selling NXP Arm Microcontroller MK22FN128VLL10 ——Kinetis K22F Series | Cortex-M4F 100 MHz | 128 KB Flash | 100 LQFP Package

Product Description

The MK22FN128VLL10 belongs to the NXP Kinetis K22F family and is packaged in an LQFP-100 (14×14mm) package. This MCU features 128 KB of Flash memory and 24 KB of SRAM, with a maximum clock frequency of 100 MHz. It is specifically designed for low-power, high-performance embedded applications and is widely used in industrial control, consumer electronics, and the Internet of Things (IoT) sectors.

MK22FN128VLL10 Key Specifications

Core Processor: ARM Cortex-M4 (with FPU)

Maximum Clock Frequency: 100MHz

Flash Memory: 128KB

SRAM Capacity: 24KB

Operating Voltage: 1.71V to 3.6V

I/O Count: 66

ADC/DAC: 2×16-bit ADC / 1×12-bit DAC

Communication Interfaces: USB OTG, I2C, SPI, UART, I2S

Operating Temperature: -40°C to +105°C

Package: LQFP-100

MK22FN128VLL10 Features

• Low power consumption: 180 µA/MHz in Run mode, < 5 µA in Stop mode

• Hardware CRC and AES-128 encryption accelerator for enhanced data security

• FlexIO can emulate UART, I²C, I²S, Camera IF and other interfaces

• Boot ROM supports USB/UART in-system programming (ISP)

• AEC-Q100 Grade 2 certified version available, suitable for automotive applications

MK22FN128VLL10 Application Areas

• Automotive body control (BCM, headlights, air conditioning, windows)

• Industrial HMI, PLC I/O modules, smart sensors

• Motor control and BLDC/PMSM drives

• Portable medical devices, blood glucose meters, blood pressure monitors

• Smart home gateways, IoT nodes, printers/scanners
