Shenzhen Mingjiada Electronics Co., Ltd.——Professional supply ON full range of power modules, covering: IGBT power modules, silicon carbide (SiC) power modules, intelligent power modules (IPM) and other products, the following is the relevant classification and typical models:

I. IGBT Power Modules

FS series (for inverter)

NXH40B120MNQ: 1200V/40A, Mini-Skim™ package, integrated NTC temperature detection.

NFAL5065L4B: 600V/50A, low inductance design, supports high frequency switching (up to 30kHz).

Automotive Grade IGBT Modules

NVG800A75L4DSC: 750V/800A, automotive grade AEC-Q certified, suitable for electric vehicle main drive inverters.

II. Silicon Carbide (SiC) Power Modules

SiC MOSFET Half Bridge Module

NXH006P120MNF2: 1200V/6mΩ, low switching loss, supports 200kHz high-frequency operation, improves system efficiency by 5%+.

NXH010P120MNF2: 1200V/10mΩ, industrial-grade package, compatible with standard driver circuit.

All-SiC Power Integration Module

NXV6TP75C1NL: 750V/6A, integrated Boost diode and MOSFET for PFC circuits, 40% size reduction.

III. Intelligent Power Module (IPM)

Miniaturised IPM

NFAM5065L4B: 600V/5A, built-in HVIC driver with bootstrap diode, simplifies PCB design.

High Power IPM

NFAL50L90BNC: 900V/50A, integrated under-voltage/over-temperature protection for air-conditioning compressor drive.

Fully Integrated Inverter Power Stage

STK984-090A-E: 40V/20A, fully integrated inverter power stage including cross-conduction protection, external shutdown and undervoltage lockout.
