Shenzhen Mingjiada Electronics Co., Ltd. has been consistently supplying STMicroelectronics' STM32L452REY6TR microcontroller: an ultra-low-power Cortex-M4 microcontroller with an integrated FPU and USB/DFSDM.

Product Overview

STMicroelectronics STM32L452REY6TR — an ultra-low-power microcontroller (MCU) based on the ARM® Cortex®-M4 core, operating at up to 80MHz, with an integrated single-precision floating-point unit (FPU) and support for DSP instruction sets, suitable for high-performance embedded systems. The chip is packaged in a 64-WLCSP (3.36×3.66mm) package, featuring 512KB of flash memory and 160KB of SRAM, along with a USB full-speed device interface and a digital filter Sigma-Delta modulator (DFSDM). It is widely used in IoT, industrial control, medical devices, and smart home applications.

Key Features

1. High-performance Cortex-M4 core with ultra-low power design

80MHz ARM Cortex-M4, supporting DSP instruction set and FPU floating-point operations, suitable for complex algorithms (e.g., motor control, digital signal processing).

Ultra-low power consumption mode: operating mode as low as 100µA/MHz, standby mode only 1.7µA (with SRAM retained), shutdown mode as low as 30nA, suitable for battery-powered devices.

Dynamic voltage regulation (DVM): optimises power consumption under different loads to extend battery life.

2. Rich peripheral interfaces

USB 2.0 full-speed device interface (supports OTG), suitable for data communication and firmware updates.

Digital filter Sigma-Delta modulator (DFSDM): supports external Σ-Δ ADC or PDM microphones, suitable for high-precision audio and sensor data acquisition.

Multi-channel communication interfaces:

CAN 2.0B (industrial control)

I²C/SPI/UART (sensor connection)

QSPI (external flash memory)

SAI (audio interface)

3. High-integration storage and security features

512KB flash memory (supports ECC) + 160KB SRAM, meeting complex firmware requirements.

Memory protection unit (MPU): enhances code security and prevents unauthorised access.

AES-256 hardware encryption (supported on some models), suitable for security-critical applications.

4. Wide Voltage Range and Industrial-Grade Reliability

1.71V to 3.6V power supply, suitable for battery or low-power power supply designs.

Operating temperature: -40°C to 85°C (industrial-grade), with some models supporting high-temperature environments up to 105°C.

Product Parameters

Manufacturer: STMicroelectronics

Product Type: ARM Microcontroller - MCU

Series: STM32L452RE

Mounting Style: SMD/SMT

Package/Case: CSP-64

Core: ARM Cortex M4

Program Memory Size: 512 kB

Data Bus Width: 32-bit

ADC Resolution: 12-bit

Maximum Clock Frequency: 80 MHz

Number of Input/Output Pins: 52 I/O

Data RAM Size: 160 kB

Power Supply Voltage - Minimum: 1.71 V

Power Supply Voltage - Maximum: 3.6 V

Minimum Operating Temperature: -40°C

Maximum Operating Temperature: +85°C

Mingjiada Electronics Supply Advantage

As a professional electronic component supplier, Mingjiada Electronics is committed to providing customers with high-quality products and services. For the STMicroelectronics STM32L452REY6TR ultra-low power microcontroller (MCU), Mingjiada Electronics offers genuine factory-direct products, ensuring that the quality and performance of the products meet international standards. The company has extensive inventory and a well-established supply chain system, enabling it to quickly respond to customer order requests and provide timely delivery services.
